1-2 channel CV dimmer with MATTER/PUSH input
Single-channel constant voltage LED dimmer with PUSH/POT/0-10V/1-10V/DALI2/PHASE-CUT input and PWM voltage output, ideal for controlling low-voltage CV LED loads. Supports isolated push input and multiple control modes selectable via DIP switches. Professional solution for 8-53V DC LED systems.
Technical specifications [L810MA04T1A01]:
- Type: Single-channel dimmer with PWM voltage output
- Input range: 8-53V DC
- Maximum output current: 13A
- Maximum power: 624W @ 48V DC (312W @ 24V DC, 156W @ 12V DC)
- Control inputs: DALI2 DT6 ×1, Insulated Push (N/O) ×1, 0-10V / 1-10V active or passive ×1, Ohm Potentiometer ×1, Switch ×1, Sensor ×1, Phase-cut ×1
- Sync output: PWM ×1
- PWM frequency: 390Hz – 3000Hz
- Functions: master/slave, programmable timed ON, configurable menu (minimum dimming, fade ON/OFF, curve, flicker-free frequency)
- Mode selection via DIP switches
- Power supply/output terminals: 0.05-3 mm² (30-12 AWG)
- UL printed circuit board
- Protection class: IP20
- Dimensions: 80 × 40 × 24.45 mm
- Required power supply: SELV
- Use: dry indoor environments
