Mono-channel phase-cut dimmer with PUSH input (500W)

Phase-cut dimmer with Push input, designed for precise light control of mains-powered LED and resistive loads. Supports AI edge (default for LED strips) or trailing edge (MOSFET) operation, with customizable settings via button menu: minimum brightness, fade in/out, linear/logarithmic dimming curve, phase-cut mode, memory and relay mode. Advanced features include double-click for maximum brightness and long-press for night light. Ideal for professional 230V installations.

Technical specifications [PUSH-230V-500W-AI]:

Type: Phase-cut dimmer (AI edge / trailing edge)
Input voltage: 80-230V AC 50/60Hz
Output power: up to 500W @ 230V
Max resistive load: 1A
Control input: Non-isolated push button ×1
Configurable menu via push button (min/max brightness, curves, relay mode, etc.)
Special functions: double-click for 100%, long-press for night light
Protections: short circuit (3A internal fuse), open circuit, voltage spikes
Accidental contact protection ensured by enclosure
Protection rating: IP20
UL printed circuit board
Terminal size: 0.12-2.5 mm² (26-14 AWG)
Operating temperature: -20°C to +50°C
Storage temperature: -40°C to +60°C
Thermal shutdown: 150°C
Use: dry environments only
